HDMI Extender

Description

A truly smart solution for HDMI CAT Extenders. You only need to power the HDMI Transmitter. The HDMI Receiver requires no power as it will receive the power automatically over the same single CAT cable as the audio & video.

Therefore, you no longer need a power supply next to the HDMI Receiver's TV. It is also super slim at only 15mm so can be easily hidden from view, behind a TV.

The TM-55 HD POE Extender enables lossless transmission of an HDMI source over single CAT cabling to a display up to 55m away.

The unique and useful HDMI Loop-through allows the HDMI Transmitter to split the video to a local TV display, saving on the cost and space of a 2-way HDMI Splitter.

Along with uncompressed 1080p HD video@60Hz with 24bit colour video transmission, full 3D compatibility, Dolby and DTS HD audio are also supported.

There is also bidirectional IR control of the source.

True EDID management by DIP switches is supported to configure handshaking between connected devices.

With the Sync button, you no longer have to use DIP switches to adjust the cable length distance. Just press the button and everything is done automatically.

Important Notice: for this extender to fully function upto 55 meters Cable Type CAT6A is to be used, for distances less than 55 meters CAT5e, Cat6 cables may be used but only where solid copper wire is used in their construction.
