Inline Power Supply 4Way 12V 5A
Item Code : TM-125-4
Product Details
Inline Power Supplies
Technomate - Inline Power Supply 4Way 12V 5A
Item Code: TM-125-4
Brand: Technomate
Manufacturer: Technomate
Description
The TM-125.4 is a 12V 5A In Line power supply with 4 output DC Plugs used to power up to 4 cameras.
The power supply is protected for safety by a Automatic Re-setting overload protection circuit.
The power supply comes complete with a UK Mains Lead fitted with IEC 6 Amp Socket and UK Square Pin Mains Plug
Features
- 12Volt 5Amp
- Can Power upto 4-8 Cameras upto a maximum load of 5Amps
- LED indicator of Power Supply Status
Specification
| Mechanical Specification | Mains Input Port | IEC 6 Amp Plug | ||
| Output Ports | 4 x DC Plug 2.1mm | |||
| Power Supply Body | 33 x 60 x 118mm (excludes cable entry requirements) | |||
| Electrical Specification | Input Voltage Range | 100-240 Volt AC | ||
| Output Voltage | 12 Volts DC | |||
| Output Current | 5 Amp | |||
| Output Power | 60W | |||
| Efficiency | < 80% | |||
| Working Temperature | -10 deg. C to +40 deg. C | |||
| Storage Temperature | -20 deg. C to +75 deg. C | |||
| Humidity | 20% - 90% | |||
| Elevation | < 3000 | |||
| Input Current: | < 1.5Amp | |||
| Input Frequency Range | 47-63Hz | |||
| Voltage Out | without load: 12 to 12.6 Volts DC with full load:11.8 to 12.6 Volts DC | |||
| Output Current Range | 0.1 to 5 Amps | |||
| Ripple and Noise | < 100 milli Volts | |||
| Start Time | < 3 seconds | |||
| Over Current Protection | 150% to 200% | |||
| Short Circuit Protection | Yes | |||
