Rack Mount Power Supply 17 Way 12V 20A

Item Code : POW572



Product Details

Antihum
  Rack Mount Power Supply

antihum - Rack Mount Power Supply 17 Way 12V 20A

Item Code: POW572

Brand: antihum

Manufacturer: antihum

Description

This Power Supply will convert the input of 240V AC  to 17 outputs of 12V with a total current output of 20 Amps.

Sixteen (16) of the output ports are fused at 2A each

One of the outputs are fused at 4A.

The power supply is protected for safety by a Automatic Re-setting overload protection circuit.

The power supply comes complete with a UK Mains Lead fitted with IEC 6 Amp Socket and UK Square Pin Mains Plug.

Features

  • 12Volt 20 Amp
  • Each output has its own individual PTC Self-resetting Fuse
  • Can Power upto 16-17 Cameras upto a maximum load of 20 Amps
  • LED indicator of Power Supply Status.

Specification

Mechanical Specification
Mains Input Port:IEC 6 Amp Plug
Output Ports:17 x DC screw terminal
Dimensions of
Power Supply Body:
236 x 300 x 67mm (excludes cable entry requirements)
Electrical Specification
Input Voltage Range:100-240 Volt AC
Output Voltage:12 Volts DC
Output Current:20 Amp
Output Power:240W
Short Circuit Protection:

Yes
