Tenda o6 - Wireless 5GHz 433Mbps Outdoor Access Point
Item Code : Tenda - o6
WiFi Access Points Outdoor
Tenda - Tenda o6 - Wireless 5GHz 433Mbps Outdoor Access Point
Item Code: Tenda - o6
Brand: Tenda
Manufacturer: Tenda
Description
This outdoor wall or Pole mounted Wireless Access Point (WiFi Transmitter/Receiver) model Tenda o6 is a stable and easy-to-use wireless access point also allows wireless Point to Point systems of upto 10 Kilo Meter. It is suitable for WIFI coverage in outdoor areas in hotels, small and medium in size, bars, cafes, large houses, WiFi for the Garden. The Tenda o6 operates in the 5GHz band with wireless speeds of up to 4330Mbps. The 06 has a 16dBi directional antenna to provide an efficient way to pick up and maintains a stable signal for a wireless network connection range up to 10 Kilo Meters. With the Simple design and elegant appearance, it can be directly installed on to walls or Mast Mounted. The o6 can also be implemented in Commercial WISP CEP Systems.
Features
- 5GHz to 433Mbps, 11AC
- IP64 waterproof enclosure
- 16dbi directional antenna
- AP,Station,WISP etc operating mode supported
- Up to 60 meters of flexible deployment included PoE Injector
Tenda - o6
|
|
Specification
| Specification | ||
|---|---|---|
| Dimension | 270*94.86*67.5mm | |
| Frequency Range | 5GHz | |
| Maximum wireless speed | 433Mbps | |
| CPU Processor | Broadcom 800MHz | |
| GND Terminal | 1 | |
| Interface | 1*GE PoE WAN LAN port | |
| Mode Switch | Station: The device only work in Station mode Off: The device work on AP/Station/Universal Repeater/WISP/Router mode AP: The device only work in AP mode | |
| Button | Reset: Press 10 seconds or more to restore to default settings Bridge: Press 3 seconds and release it to bridge uplink AP | |
| Antenna | 16dbi Directional Antenna | |
| Antenna Beamwidth | Horizontal: 30° Vertical: 15° | |
| Maximum Consumption | 9W | |
| Lightning Protection | 6KV | |
| Waterproof Level | IP64 | |
| LED | LAN LED1 LED2 LED3 | |
| Power Supply | 24v 0.5A PoE Injector | |
| Operating mode | AP/Station/Universal Repeater/WISP/Router | |
| Standard&Protocol | IEEE 802.11ac/n/a | |
| Wireless Speed | Enable/Disable Wireless Radio SSID Hidden Wireless Client isolation Sensitivity Threshold WMM Capable APSD Capable Wireless Access Control Wireless Client list | |
| Wireless Security | 64/128 WEP WPA-PSK WPA2-PSK WPA&WPA2-PSK WPA WPA2 | |
| Transmit Power | Adjustable power by 1dBm | |
| Reception Sensitivity | MCS0: -90dbm MCS7: -72dbm | |
| DHCP Server | DHCP Server Clients list | |
| VPN Pass-through | PPTP L2TP | |
| Ping Watchdog | Support | |
| Speed Test | Support | |
| Remote Web access | Support | |
| Schedule Reboot | Support | |
| Page Timeout | Support | |
| Dyndns oip dyndns.org | ||
| Network Diagnoses | Ping Traceroute Signal Scan | |
| Management Tool | Time&Date Setting System Log Firmware update Backup/Restore Configuration Username Managerment | |
| Temperature | Operating Temperature:-20℃ ~ 55℃ Storage Temperature:-40℃ ~ 70℃ | |
| Humidity | Operating Humidity:10%~90% non-condensing Storage Humidity:10%~90% non-condensing | |
| Default Settings | IP Address: 192.168.2.1 Login Username:admin Login Password:admin | |
| Certification | FCC CE RoHS | |
