ProPSU11F
Item Code : RF Line Power Supply 12V 100mA
Special Notice: None
Special Notice: None
Power Supplies
Proception - ProPSU11F
Item Code: RF Line Power Supply 12V 100mA
Brand: Proception
Manufacturer: Blake UK
RF Line Power Supply 12V 100mA
Description
High-quality 12 volt coaxical in-line power unit for use with the PROception range of masthead amplifiers and similar applications. The unit utilise an efficient cooling-running mains transformers, fitted with an approved thermal fuse for overheat protection. The two-colour power indicator LED gives immediate warning of an output short-circuit condition. Regulation is maintained over the full 207-253 V AC supply voltage range, for any output current up to the maximum of 100 mA.
Designs independently certified to relevant safety standard BS EN 60065.
Features
- Fully-screened RF modules, compliant with EMC standards (BS EN 55013 & BS EN 50083-2).
- Low RF insertion loss and excellent 75 Ω impedance matching.
- Passes return path signals, allowing use in IR eye systems (proPSU11F MK 2 only).
- Electronic long-term short-circuit protection with two-colour LED indication.
Specification
| Product Code | ProPSU11F MK2 | |
| Input | one | |
| Output | one | |
| Insertion Loss | 0.6dB | |
| Power | Output Voltage: 12Volts | |
| Maximum Current: 100mA | ||
| Short circuit warning | Yes | |
| Signal Frequency Range | 5-862MHz | |
| Mains Plug | fitted with UK Plug of rectangular pins to BS1363 | |
| Applications | Power Supply for Mast Head Amplifiers. |
